Diodes Incorporated RS1M-13-F
RS1M-13-F Supplier & Distributor
RS1M-13-F is an electronic component manufactured by Diodes Incorporated. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply RS1M-13-F with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- RS1M-13-F
- Manufacturer:
- Diodes Incorporated
- Category:
- In-Stock Discrete Semiconductors
- Package:
- DO-214AC, SMA
- Datasheet:
-
RS1M-13-F.pdf
- Description:
- DIODE GEN PURP 1KV 1A SMA
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Inventory:35,704
Send us your inquiry,we will respond immediately.
About RS1M-13-F
Looking for RS1M-13-F supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of RS1M-13-F.
Product Details
RS1M-13-F – Diodes Incorporated 1000V 1A Surface-Mount Fast Recovery Rectifier
RS1M-13-F is a Diodes Incorporated surface-mount fast recovery rectifier designed for high-voltage rectification, switching power supply output stages, freewheeling paths and general-purpose diode positions. With 1000V repetitive peak reverse voltage, 1A average forward current, 1.3V maximum forward voltage, 500ns reverse recovery time, 30A surge current and SMA / DO-214AC package, it is suitable for compact power boards, adapters, LED drivers, industrial control circuits, consumer electronics and general high-voltage rectifier applications.
Engineering note: Confirm reverse voltage margin, average current, recovery time, surge current, thermal derating, PCB copper area, polarity marking and the latest Diodes Incorporated datasheet before production approval.
Component Overview
RS1M-13-F belongs to the Diodes Incorporated RS1A/B–RS1M/B family of 1.0A surface-mount fast recovery rectifiers. It uses glass-passivated die construction and provides fast recovery performance for efficient rectification in compact SMD power circuits. The device is designed for automated assembly and high-voltage applications requiring a standard SMA footprint.
Circuit Function & Design Role
Provides efficient rectification where faster reverse recovery is needed than standard low-speed rectifiers.
1000V reverse-voltage rating supports AC/DC and high-voltage switching power circuits.
Can be used in inductive switching paths where reverse recovery behavior must be considered.
SMA / DO-214AC package supports automated assembly and compact board-level power designs.
Key Electrical & Package Information
| Manufacturer | Diodes Incorporated |
|---|---|
| Part Number | RS1M-13-F |
| Series | RS1A/B–RS1M/B Series |
| Device Type | Surface-mount fast recovery rectifier |
| Configuration | Single diode |
| Peak Repetitive Reverse Voltage | 1000V |
| Average Forward Current | 1A |
| Forward Voltage | 1.3V max at 1A |
| Reverse Current | 5µA max at rated DC blocking voltage, +25°C reference condition |
| Reverse Recovery Time | 500ns max reference value |
| Forward Surge Current | 30A peak |
| Total Capacitance | 15pF typical reference value |
| Technology | Fast recovery rectifier / glass passivated die |
| Package / Case | SMA / DO-214AC |
| Mounting Type | Surface Mount / SMD |
| Pin Count | 2 pins |
| Operating Temperature | -65°C to +150°C reference range |
| Packaging | Tape and reel / cut tape options |
| Reel Quantity | 5,000 pcs reference reel quantity |
| Product Status | Active |
Application Scenarios
Switching Power Supplies
Used in rectifier and recovery-sensitive diode positions in compact switching power circuits.
Adapters & Chargers
Suitable for high-voltage rectification and protection positions in adapters, chargers and small AC/DC boards.
LED Drivers
Applicable to compact LED driver boards requiring a 1000V 1A SMD fast recovery diode.
Industrial & Consumer Boards
Useful in control modules, consumer electronics and general power-management circuits.
TomatoElec Quality & Supply Notes
As an in-stock independent distributor and electronic components supplier, TomatoElec supports RS1M-13-F sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For rectifier diodes, correct manufacturer, voltage rating, current rating, package, polarity marking, reel suffix, date code and original sourcing are important because the device affects rectification efficiency, switching behavior and long-term circuit reliability.
- Original component sourcing: support sourcing of original Diodes Incorporated fast recovery rectifier products.
- Inventory support: help confirm available stock, package condition, date code and shipment schedule.
- Package verification: confirm SMA / DO-214AC package and -13-F tape-and-reel ordering information before shipment.
- BOM matching: verify reverse voltage, current rating, reverse recovery time, forward voltage, surge current, package and temperature range before approving any substitute.
Replacement & BOM Matching Guidance
RS1M-13-F should not be replaced only by matching "1000V 1A diode." Engineers should compare reverse recovery time, forward voltage, leakage current, surge current, SMA footprint, package height, polarity marking and thermal behavior.
FAQ
What is RS1M-13-F used for?
Is RS1M-13-F a Schottky diode?
What package is RS1M-13-F?
Can TomatoElec support RS1M-13-F sourcing?
Final Selection Summary
RS1M-13-F is a Diodes Incorporated 1000V, 1A surface-mount fast recovery rectifier in SMA / DO-214AC package for high-voltage rectification, switching power circuits and compact SMD power-board designs.
