Diodes Incorporated AL1697-20CS7-13
AL1697-20CS7-13 Supplier & Distributor
AL1697-20CS7-13 is an electronic component manufactured by Diodes Incorporated. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply AL1697-20CS7-13 with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- AL1697-20CS7-13
- Manufacturer:
- Diodes Incorporated
- Category:
- In-Stock Discrete Semiconductors
- Package:
- 8-SOIC (0.154", 3.90mm Width), 7 Leads
- Datasheet:
-
AL1697-20CS7-13.pdf
- Description:
- IC LED DRIVER OFFL TRIAC 2A 7SO
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Inventory:0
Send us your inquiry,we will respond immediately.
About AL1697-20CS7-13
Looking for AL1697-20CS7-13 supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of AL1697-20CS7-13.
Product Details
AL1697-20CS7-13 – Diodes Incorporated High-PF Offline Dimmable LED Driver
AL1697-20CS7-13 is a Diodes Incorporated high-performance offline dimmable LED driver designed for mains dimmable LED lamp and offline LED power supply applications. It integrates a high-voltage MOSFET and supports high power factor, high efficiency, accurate output current regulation and wide dimmer compatibility in compact LED lighting designs. The AL1697-20C option supports a 600V / 2A internal MOSFET, SO-7 package, Triac dimming, 130V maximum output voltage and 200mA maximum LED current.
Engineering note: Confirm LED string voltage, dimmer compatibility, current setting resistor, thermal design, EMI margin, isolation requirement and the latest Diodes Incorporated datasheet before production approval.
Component Overview
AL1697-20CS7-13 belongs to the Diodes Incorporated AL1697 family of high-PF, offline dimmable LED drivers with an internal high-voltage MOSFET. It is designed for compact LED retrofit lamps and offline LED driver boards where designers need Triac dimming, high power factor and accurate LED current regulation with reduced external component count.
Circuit Function & Design Role
Controls LED current in mains-powered LED lamps and offline LED power supply designs.
Supports dimmable lamp designs requiring compatibility with leading-edge and trailing-edge dimmers.
Reduces external component count by integrating the high-voltage MOSFET inside the controller.
Supports high power factor and boundary conduction mode operation to help efficiency and EMI design.
Key Electrical & Package Information
| Manufacturer | Diodes Incorporated |
|---|---|
| Part Number | AL1697-20CS7-13 |
| Series | AL1697 Series |
| Device Type | High-PF offline dimmable LED driver |
| Integrated MOSFET Option | 600V / 2A internal high-voltage MOSFET |
| Topology | Buck-Boost / Flyback |
| Dimming Type | Triac dimming |
| Input AC Voltage Range | 85VAC to 265VAC |
| Maximum VDD | 18V |
| Maximum Output Voltage | 130V |
| Maximum LED Current | 200mA |
| Current Accuracy | ±3% |
| Typical Efficiency | 85% |
| Startup Current | 130µA |
| Operating Current | 170µA typical reference value |
| Package / Case | SO-7 |
| Mounting Type | Surface Mount / SMD |
| Operating Temperature | -40°C to +105°C |
| Packaging | Tape and reel |
| Reel Quantity | 4,000 pcs |
Application Scenarios
Dimmable LED Lamps
Used in mains dimmable LED lamp designs requiring high PF and Triac dimming compatibility.
LED Retrofit Lighting
Suitable for compact retrofit lamp power stages where small PCB size and low BOM cost are important.
Offline LED Power Supplies
Applicable to isolated or non-isolated LED power supply driver designs using buck-boost or flyback topology.
General Lighting Boards
Useful where a BOM requires an SO-7 offline LED driver with integrated 600V / 2A MOSFET.
TomatoElec Quality & Supply Notes
As an in-stock independent distributor and electronic components supplier, TomatoElec supports AL1697-20CS7-13 sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For offline LED driver ICs, correct manufacturer, orderable part number, package code, reel suffix, date code, moisture handling and original sourcing are important because the device directly affects lighting stability, dimming behavior and long-term reliability.
- Original component sourcing: support sourcing of original Diodes Incorporated LED driver IC products.
- Inventory support: help confirm available stock, package condition, date code and shipment schedule.
- Package verification: confirm SO-7 package, S7 package code and -13 tape-and-reel suffix before shipment.
- BOM matching: verify topology, MOSFET option, dimming requirement, LED current range, package and operating temperature before approving any substitute.
Replacement & BOM Matching Guidance
AL1697-20CS7-13 should not be replaced only by matching the AL1697 series name. Engineers should compare MOSFET voltage/current option, maximum output voltage, LED current setting, topology, dimmer compatibility, protection behavior, package, thermal design and PCB footprint.
FAQ
What is AL1697-20CS7-13 used for?
What is the package of AL1697-20CS7-13?
What internal MOSFET option does AL1697-20CS7-13 use?
Can TomatoElec support AL1697-20CS7-13 sourcing?
Final Selection Summary
AL1697-20CS7-13 is a Diodes Incorporated high-PF offline dimmable LED driver with integrated 600V / 2A MOSFET, SO-7 package and Triac dimming support for compact LED lamp power designs.
AL1697-20CS7-13 Specifications
- Specifications
- FAQ
- The Posts
- Attributes
- Property Value
- Manufacturer
- Diodes Incorporated
- Package/Case:
- 8-SOIC (0.154", 3.90mm Width), 7 Leads
- Packaging:
- Tape & Reel (TR)
- Current - Output High, Low:
- 18V
- Max Propagation Delay @ V, Max CL:
- 600V
- Current - Quiescent (Iq):
- 2A
- Operating Temperature:
- -
- Grade:
- Triac
- Qualification:
- -
- Supplier Device Package:
- -40°C ~ 105°C (TA)
- Mounting Type:
- -
- Supplier Device Package:
- -
- Supplier Device Package:
- Surface Mount
- Mounting Type:
- 7-SO
- Supplier Device Package:
- Supplier Device Package:
- Supplier Device Package:
- Category:
- In-Stock Discrete Semiconductors
1. How to order AL1697-20CS7-13 from Hong Kong Tomato Electronics Co., Limited?
You can submit an RFQ for AL1697-20CS7-13 directly on our website. After receiving your request, our sales team will contact you with price, availability, lead time and order details. Once you confirm the quotation, we will help you complete the order process.
2. How does Hong Kong Tomato Electronics Co., Limited ensure that AL1697-20CS7-13 is original and reliable?
Hong Kong Tomato Electronics Co., Limited works with qualified supply channels and applies strict quality control procedures for electronic components including AL1697-20CS7-13. We pay close attention to supplier screening, product verification and delivery quality to help customers source with confidence.
3. Are the price and inventory of AL1697-20CS7-13 accurate?
The price and inventory of AL1697-20CS7-13 may change due to market conditions and stock movement. We update information as frequently as possible, but final quotation and availability should be confirmed by our sales team. In most cases, quotations are valid for 3 to 5 days.
4. What payment methods are accepted?
We usually accept Wire Transfer, PayPal, Alipay, WeChat Pay, Credit Card, Western Union and other agreed payment methods, depending on the order and customer location.
Please note that some payment methods may involve additional handling charges.
5. How is the shipping arranged?
Customers can choose major international carriers such as DHL, UPS, FedEx and other available shipping methods. Shipping options depend on package size, destination and delivery urgency.
After shipment, our team will send you the shipping status and tracking number by email.
Please note that tracking information may take some time to become active after dispatch.
6. What is the return or replacement policy for AL1697-20CS7-13?
All shipments are checked before dispatch. If there is a confirmed issue related to the delivered AL1697-20CS7-13, such as incorrect quantity, wrong item or verified product problem, please contact us as soon as possible.
Return or replacement requests are usually accepted only when the part remains unused and in its original packaging, and when the issue is reported within the agreed time after delivery.
Please contact our team first before returning any goods so that we can confirm the issue and provide return instructions.
7. How can I get technical support, such as the datasheet or specifications for AL1697-20CS7-13?
If you need technical support for AL1697-20CS7-13, including datasheets, specifications or general product information, please contact our sales team. We will do our best to help you obtain the relevant information.
-
