Texas Instruments UCC27201ADRCR
UCC27201ADRCR Supplier & Distributor
UCC27201ADRCR is an electronic component manufactured by Texas Instruments. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply UCC27201ADRCR with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- UCC27201ADRCR
- Manufacturer:
- Texas Instruments
- Category:
- In-Stock Integrated Circuits (ICs）
- Package:
- 10-VFDFN Exposed Pad, 9 Leads
- Datasheet:
-
UCC27201ADRCR.pdf
- Description:
- IC GATE DRVR HALF-BRIDGE 9VSON
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Inventory:4,220
Send us your inquiry,we will respond immediately.
About UCC27201ADRCR
Looking for UCC27201ADRCR supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of UCC27201ADRCR.
Product Details
UCC27201ADRCR – TI 120V 3A Half-Bridge Gate Driver with 8V UVLO
UCC27201ADRCR is a Texas Instruments high-frequency half-bridge gate driver designed to drive two N-channel MOSFETs in high-side and low-side configurations. With a 120V maximum bootstrap voltage, 3A source and 3A sink drive current, 8V undervoltage lockout, TTL-compatible inputs, integrated bootstrap diode and compact 9-pin VSON package, it is suitable for DC/DC converters, motor drives, half-bridge stages, full-bridge converters, active clamp forward converters and high-frequency power switching designs.
Engineering note: Verify the latest TI datasheet, bootstrap capacitor selection, HS negative voltage margin, gate resistor values, dead-time control, switching-node layout and thermal performance before production approval.
Component Overview
UCC27201ADRCR belongs to the TI UCC27201A family of 120V half-bridge gate drivers with TTL-compatible inputs. It provides independent high-side and low-side gate-drive control for N-channel MOSFET power stages, helping designers build compact and efficient switching power circuits.
Circuit Function & Design Role
Drives high-side and low-side N-channel MOSFETs in synchronous buck, bridge and switching power stages.
Fast rise and fall times support efficient switching when gate loop layout and drive resistance are properly designed.
Integrated bootstrap diode helps simplify the high-side floating driver supply design.
Negative voltage handling on the HS pin improves tolerance in noisy power-stage environments.
Key Electrical & Package Information
| Manufacturer | Texas Instruments |
|---|---|
| Part Number | UCC27201ADRCR |
| Device Type | High-side / low-side half-bridge gate driver |
| Driver Configuration | Non-inverting half-bridge driver |
| Bootstrap Voltage | 120V max |
| VDD Operating Range | 8V to 17V |
| VDD Maximum Rating | 20V max |
| Peak Output Current | 3A source / 3A sink |
| UVLO | 8V typical for high-side and low-side driver |
| Input Logic | TTL-compatible inputs |
| Propagation Delay | 22ns typical |
| Rise / Fall Time | 8ns rise / 7ns fall with 1000pF load |
| Delay Matching | 1ns typical |
| HS Negative Voltage Handling | -18V max |
| Bootstrap Diode | Integrated bootstrap diode |
| Package | DRC / 9-pin VSON, 3mm × 3mm |
| Carrier | 3,000 pcs / large tape and reel |
| Operating Temperature | -40°C to +150°C |
| Product Status | Active |
Application Scenarios
DC/DC Converters
Used in synchronous buck, two-switch forward and active clamp power converter designs.
Motor Drive Power Stages
Suitable for half-bridge and full-bridge MOSFET drive stages in motor control systems.
48V Power Systems
Applicable to auxiliary power, bidirectional DC/DC converters and high-frequency switching rails.
Industrial Power Boards
Useful for compact industrial control boards requiring robust high-side and low-side gate drive.
TomatoElec Quality & Supply Notes
As an in-stock independent distributor and electronic components supplier, TomatoElec supports UCC27201ADRCR sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For gate driver ICs, correct orderable part number, package type, reel condition, date code and original sourcing are important because the device affects MOSFET switching behavior, power-stage efficiency and long-term system reliability.
- Original component sourcing: support sourcing of original Texas Instruments gate driver ICs.
- Inventory support: help confirm available stock, package condition, date code and shipment schedule.
- Package verification: confirm DRC / VSON-9 package and large tape-and-reel carrier before shipment.
- BOM matching: verify bootstrap voltage, drive current, UVLO threshold, input logic, package, pinout and temperature requirements before approving any substitute.
Replacement & BOM Matching Guidance
UCC27201ADRCR should not be replaced only by matching the 120V half-bridge driver category. Engineers should compare drive current, UVLO threshold, input logic level, propagation delay, delay matching, HS negative-voltage rating, bootstrap diode behavior, package, pinout and thermal conditions.
FAQ
What is UCC27201ADRCR used for?
Does UCC27201ADRCR include a bootstrap diode?
What package is UCC27201ADRCR?
Can TomatoElec support UCC27201ADRCR sourcing?
Final Selection Summary
UCC27201ADRCR is a compact 120V, 3A/3A half-bridge gate driver for designs requiring TTL inputs, 8V UVLO, integrated bootstrap diode, negative HS voltage handling and VSON-9 packaging.
UCC27201ADRCR Specifications
- Specifications
- FAQ
- The Posts
- Attributes
- Property Value
- Manufacturer
- Texas Instruments
- Package/Case:
- 10-VFDFN Exposed Pad, 9 Leads
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Not Verified
- Number of Bits:
- Half-Bridge
- Output:
- Independent
- Output Function:
- 2
- Voltage - Supply:
- N-Channel MOSFET
- Current - Output High, Low:
- 8V ~ 17V
- Max Propagation Delay @ V, Max CL:
- 0.8V, 2.5V
- Current - Quiescent (Iq):
- 3A, 3A
- Operating Temperature:
- Non-Inverting
- Grade:
- 120 V
- Qualification:
- 8ns, 7ns
- Supplier Device Package:
- -40°C ~ 140°C (TJ)
- Mounting Type:
- -
- Supplier Device Package:
- -
- Supplier Device Package:
- Surface Mount
- Mounting Type:
- 9-VSON (3x3)
- Supplier Device Package:
- Supplier Device Package:
- Supplier Device Package:
- Current Rating (Amps):
- Category:
- In-Stock Integrated Circuits (ICs）
1. How to order UCC27201ADRCR from Hong Kong Tomato Electronics Co., Limited?
You can submit an RFQ for UCC27201ADRCR directly on our website. After receiving your request, our sales team will contact you with price, availability, lead time and order details. Once you confirm the quotation, we will help you complete the order process.
2. How does Hong Kong Tomato Electronics Co., Limited ensure that UCC27201ADRCR is original and reliable?
Hong Kong Tomato Electronics Co., Limited works with qualified supply channels and applies strict quality control procedures for electronic components including UCC27201ADRCR. We pay close attention to supplier screening, product verification and delivery quality to help customers source with confidence.
3. Are the price and inventory of UCC27201ADRCR accurate?
The price and inventory of UCC27201ADRCR may change due to market conditions and stock movement. We update information as frequently as possible, but final quotation and availability should be confirmed by our sales team. In most cases, quotations are valid for 3 to 5 days.
4. What payment methods are accepted?
We usually accept Wire Transfer, PayPal, Alipay, WeChat Pay, Credit Card, Western Union and other agreed payment methods, depending on the order and customer location.
Please note that some payment methods may involve additional handling charges.
5. How is the shipping arranged?
Customers can choose major international carriers such as DHL, UPS, FedEx and other available shipping methods. Shipping options depend on package size, destination and delivery urgency.
After shipment, our team will send you the shipping status and tracking number by email.
Please note that tracking information may take some time to become active after dispatch.
6. What is the return or replacement policy for UCC27201ADRCR?
All shipments are checked before dispatch. If there is a confirmed issue related to the delivered UCC27201ADRCR, such as incorrect quantity, wrong item or verified product problem, please contact us as soon as possible.
Return or replacement requests are usually accepted only when the part remains unused and in its original packaging, and when the issue is reported within the agreed time after delivery.
Please contact our team first before returning any goods so that we can confirm the issue and provide return instructions.
7. How can I get technical support, such as the datasheet or specifications for UCC27201ADRCR?
If you need technical support for UCC27201ADRCR, including datasheets, specifications or general product information, please contact our sales team. We will do our best to help you obtain the relevant information.
-
