Texas Instruments TPS54560DDAR
TPS54560DDAR Supplier & Distributor
TPS54560DDAR is an electronic component manufactured by Texas Instruments. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply TPS54560DDAR with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- TPS54560DDAR
- Manufacturer:
- Texas Instruments
- Category:
- In-Stock Integrated Circuits (ICs）
- Package:
- 8-PowerSOIC (0.154", 3.90mm Width)
- Datasheet:
-
TPS54560DDAR.pdf
- Description:
- IC REG BCK SPLIT RAIL ADJ 8SOPWR
- Quantity:
Unit Price:$1.841000
Ext Price:$1.841000
- Payment:
- Shipping:
Inventory:12,000
Send us your inquiry,we will respond immediately.
Stock:12,000
| Qty. | Unit Price | Ext Price |
| 1+ | $1.841000 | $1.841000 |
| 10+ | $1.617700 | $16.177000 |
| 25+ | $1.526000 | $38.150000 |
| 100+ | $1.271340 | $127.134000 |
| 250+ | $1.219932 | $304.983000 |
| 500+ | $1.076768 | $538.384000 |
| 1000+ | $0.876540 | $876.540000 |
About TPS54560DDAR
Looking for TPS54560DDAR supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of TPS54560DDAR.
Product Details
TPS54560DDAR – TI 60V Input, 5A Step-Down DC/DC Converter with Eco-mode™
TPS54560DDAR is a Texas Instruments wide-input step-down DC/DC converter designed for efficient voltage conversion in industrial, automotive accessory, communication and distributed power systems. With a 4.5V to 60V input range, 5A output capability, integrated high-side MOSFET, Eco-mode™ light-load operation and thermally enhanced 8-pin HSOIC PowerPAD package, it is suitable for 12V, 24V and 48V rails, industrial automation, motor control, battery chargers, vehicle accessories and rugged point-of-load power supplies.
Engineering note: Verify the latest TI datasheet, thermal design, switching frequency setting, compensation network, diode selection, PCB layout and input transient margin before production approval.
Component Overview
TPS54560DDAR belongs to the TI TPS54560 family of 60V, 5A step-down regulators with an integrated high-side MOSFET. It converts high or variable input rails into regulated lower output voltages for control boards, communication modules, industrial systems and downstream point-of-load circuits.
Circuit Function & Design Role
Converts 12V, 24V, 48V and other high input rails into stable lower voltages for system electronics.
Provides up to 5A output current for intermediate rails, local power supplies and higher-load control boards.
Eco-mode™ pulse skipping helps reduce no-load and light-load power consumption in standby systems.
Current-mode control, adjustable UVLO and wide switching-frequency range support flexible component selection.
Key Electrical & Package Information
| Manufacturer | Texas Instruments |
|---|---|
| Part Number | TPS54560DDAR |
| Device Type | Step-down DC/DC converter |
| Topology | Buck regulator with integrated high-side MOSFET |
| Input Voltage Range | 4.5V to 60V |
| Output Voltage Range | 0.8V to 58.8V |
| Output Current | 5A max |
| High-Side MOSFET | 92mΩ integrated MOSFET |
| Switching Frequency | 100kHz to 2.5MHz |
| Control Mode | Current-mode control |
| Operating Quiescent Current | 146µA typical |
| Shutdown Current | 2µA typical |
| Internal Reference | 0.8V, 1% |
| Duty Cycle | 98% max |
| Package | DDA / 8-pin HSOIC PowerPAD |
| Carrier | Large tape and reel |
| Operating Temperature | -40°C to +150°C |
| Product Status | Active |
Application Scenarios
Industrial Automation
Used in factory automation, PLC modules, distributed control systems and industrial power boards.
Motor Control Systems
Suitable for auxiliary rails in motor drives and control electronics operating from higher voltage inputs.
12V / 24V / 48V Rails
Applicable to industrial, automotive accessory and communication systems requiring wide-input step-down conversion.
Battery Chargers & USB Power
Can be used in battery charger power paths and USB dedicated charging port power designs when properly validated.
TomatoElec Quality & Supply Notes
As an in-stock independent distributor and electronic components supplier, TomatoElec supports TPS54560DDAR sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For high-current power converters, correct orderable part number, package type, reel condition, date code and original sourcing are important because the device affects efficiency, thermal behavior and long-term power reliability.
- Original component sourcing: support sourcing of original Texas Instruments power management ICs.
- Inventory support: help confirm available stock, package condition, date code and shipment schedule.
- Package verification: confirm DDA / HSOIC-8 PowerPAD package and large tape-and-reel carrier before shipment.
- BOM matching: verify input range, output current, switching frequency, package, thermal requirement and system voltage before approving any substitute.
Replacement & BOM Matching Guidance
TPS54560DDAR should not be replaced only by matching 60V input and 5A output current. Engineers should compare switching frequency, compensation method, pinout, package, MOSFET resistance, current limit, UVLO behavior, thermal resistance, external diode requirements and EMI performance.
FAQ
What is TPS54560DDAR used for?
Is TPS54560DDAR the same as TPS54560BDDAR?
Is TPS54560DDAR a synchronous buck converter?
Can TomatoElec support TPS54560DDAR sourcing?
Final Selection Summary
TPS54560DDAR is a rugged 60V, 5A step-down DC/DC converter for designs requiring wide input voltage, Eco-mode light-load efficiency, adjustable switching frequency and thermally enhanced HSOIC PowerPAD packaging.
