Diodes Incorporated PT7C4337WEX
PT7C4337WEX Supplier & Distributor
PT7C4337WEX is an electronic component manufactured by Diodes Incorporated. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply PT7C4337WEX with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- PT7C4337WEX
- Manufacturer:
- Diodes Incorporated
- Category:
- Real Time Clocks
- Package:
- 8-SOIC (0.154", 3.90mm Width)
- Datasheet:
-
PT7C4337WEX.pdf
- Description:
- IC RTC CLK/CALENDAR I2C 8SOIC
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Inventory:4,221
Send us your inquiry,we will respond immediately.
About PT7C4337WEX
Looking for PT7C4337WEX supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of PT7C4337WEX.
Product Details
PT7C4337WEX – Diodes Incorporated Low-Power I2C Real-Time Clock / Calendar IC
PT7C4337WEX is a Diodes Incorporated low-power serial real-time clock and calendar IC designed for timekeeping, date tracking, alarm generation and square-wave output functions in embedded electronic systems. With I2C / 2-wire serial interface, external 32.768kHz crystal support, 12-hour and 24-hour time format, seconds, minutes, hours, day, date, month and year counters, two programmable alarms, programmable square-wave output, 1.8V to 5.5V operating range and 8-SOIC package, it is suitable for control boards, security devices, consumer electronics, industrial modules, data logging systems and general timekeeping designs.
Engineering note: Confirm 32.768kHz crystal load capacitance, I2C pull-up resistor values, alarm interrupt routing, square-wave output setting, timekeeping voltage range and the latest Diodes Incorporated datasheet before production approval.
Component Overview
PT7C4337WEX belongs to the Diodes Incorporated PT7C4337 family of low-power I2C real-time clock devices. It provides clock and calendar information through a 2-wire serial interface and supports automatic adjustment for months with fewer than 31 days, including leap-year correction. The device is useful when a microcontroller, processor or embedded system needs reliable time and date tracking without using many host pins.
Circuit Function & Design Role
Maintains seconds, minutes, hours, date, day, month and year information for embedded systems.
Uses a 2-wire serial bus to reduce host pin count while providing RTC register access.
Supports programmable alarm functions for time-based wake-up, event timing or system notification.
Provides a programmable square-wave output that can be used for timing or reference clock functions.
Key Electrical & Package Information
| Manufacturer | Diodes Incorporated |
|---|---|
| Part Number | PT7C4337WEX |
| Series | PT7C4337 Series |
| Device Type | Real-time clock / calendar IC |
| Interface | I2C / 2-wire serial bus |
| Maximum Bus Speed | 400kHz reference value |
| Crystal Requirement | External 32.768kHz quartz crystal |
| Time Format | HH:MM:SS, 12-hour or 24-hour format |
| Date Format | YY-MM-DD-dd |
| Calendar Function | Seconds, minutes, hours, day, date, month and year counters |
| Leap-Year Correction | Supported |
| Alarm Function | Two programmable time-of-day alarms |
| Square-Wave Output | Programmable square-wave output |
| Oscillator Monitoring | Oscillator Stop Flag |
| Operating Supply Voltage | 1.8V to 5.5V |
| Low-Voltage Timekeeping | Timekeeping maintained down to 1.2V reference condition |
| Timekeeping Current | 0.8µA max reference value at low-voltage timekeeping condition |
| Package / Case | 8-SOIC, 150mil wide |
| Mounting Type | Surface Mount / SMD |
| Operating Temperature | -40°C to +85°C |
| Packaging | Tape and reel / cut tape options |
| Product Status | Active |
Application Scenarios
Embedded Control Boards
Provides clock and calendar functions for MCU-based control systems and compact embedded boards.
Security & Access Devices
Useful in security equipment, access control, event logging and time-stamped monitoring systems.
Industrial Modules
Applicable to data loggers, metering modules, automation devices and equipment status records.
Consumer Electronics
Suitable for appliances, displays, portable products and user-interface systems requiring time tracking.
TomatoElec Quality & Supply Notes
As an in-stock independent distributor and electronic components supplier, TomatoElec supports PT7C4337WEX sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For RTC and timing ICs, correct manufacturer, package code, reel suffix, date code, moisture handling and original sourcing are important because the device affects timekeeping accuracy, firmware compatibility and long-term system reliability.
- Original component sourcing: support sourcing of original Diodes Incorporated RTC and timing IC products.
- Inventory support: help confirm available stock, package condition, date code and shipment schedule.
- Package verification: confirm W / 8-SOIC package and X tape-and-reel ordering information before shipment.
- BOM matching: verify interface, supply range, timekeeping current, alarm functions, package and temperature range before approving any substitute.
Replacement & BOM Matching Guidance
PT7C4337WEX should not be replaced only by matching "I2C RTC." Engineers should compare register map, alarm behavior, oscillator circuit, square-wave output, supply voltage, timekeeping current, package footprint and firmware compatibility.
FAQ
What is PT7C4337WEX used for?
Does PT7C4337WEX use I2C?
What package is PT7C4337WEX?
Can TomatoElec support PT7C4337WEX sourcing?
Final Selection Summary
PT7C4337WEX is a Diodes Incorporated low-power I2C real-time clock/calendar IC in 8-SOIC package for timekeeping, alarm generation, square-wave output and embedded clock/calendar applications.
