Diodes Incorporated AZ34063UMTR-G1
AZ34063UMTR-G1 Supplier & Distributor
AZ34063UMTR-G1 is an electronic component manufactured by Diodes Incorporated. We are a professional electronic components supplier providing original parts with large stock available in Shenzhen Huaqiangbei.
We supply AZ34063UMTR-G1 with competitive pricing, fast global delivery and reliable sourcing services for OEM, EMS and electronic trading companies.
- Original and genuine components
- Large stock inventory available
- Fast worldwide shipping
- Support for bulk orders
- Part No.:
- AZ34063UMTR-G1
- Manufacturer:
- Diodes Incorporated
- Category:
- In-Stock Discrete Semiconductors
- Package:
- 8-SOIC (0.154", 3.90mm Width)
- Datasheet:
-
AZ34063UMTR-G1.pdf
- Description:
- IC REG BUCK BOOST ADJ 1.5A 8SOIC
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Inventory:73,972
Send us your inquiry,we will respond immediately.
About AZ34063UMTR-G1
Looking for AZ34063UMTR-G1 supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.
Contact us now for quotation and availability of AZ34063UMTR-G1.
Product Details
AZ34063UMTR-G1 – Diodes Incorporated 1.5A Step-Down / Step-Up / Inverting DC-DC Converter
AZ34063UMTR-G1 is a Diodes Incorporated monolithic switching regulator control IC designed for step-down, step-up and voltage-inverting DC/DC converter circuits. With a 3.0V to 36V input range, 1.5A output switch current, adjustable output voltage, operation frequency up to 180kHz, precision 2% reference and 8-SOIC package, it is suitable for general power conversion, auxiliary rails, embedded control boards, consumer electronics and cost-sensitive DC/DC regulator designs.
Engineering note: Confirm topology, inductor value, Schottky diode rating, timing capacitor, current-sense resistor, output capacitor ESR, thermal margin and the latest Diodes Incorporated datasheet before production approval.
Component Overview
AZ34063UMTR-G1 belongs to the Diodes Incorporated AZ34063U family of 1.5A switching regulator control circuits. It contains the core blocks required for basic DC/DC conversion, including a temperature-compensated reference, oscillator, driver, current-limit function and high-current output switch. Unlike modern fully synchronous buck regulators, this device normally requires external passive components and an external rectifier diode to complete the converter design.
Circuit Function & Design Role
Can be configured as a buck converter to generate lower regulated rails from a higher input voltage.
Can be configured as a boost converter for applications requiring an output voltage higher than the input rail.
Supports inverting converter designs for generating negative rails from a positive input supply.
Provides a cost-effective controller architecture for auxiliary and general-purpose DC/DC rails.
Key Electrical & Package Information
| Manufacturer | Diodes Incorporated |
|---|---|
| Part Number | AZ34063UMTR-G1 |
| Series | AZ34063U / AZ34063 Series |
| Device Type | Switching regulator control IC |
| Supported Topologies | Step-down, step-up, voltage-inverting |
| Output Configuration | Positive or negative adjustable |
| Number of Outputs | 1 |
| Input Voltage Range | 3.0V to 36V |
| Reference Voltage | 1.25V nominal reference |
| Output Switch Current | 1.5A |
| Switching Frequency | Up to 180kHz |
| Synchronous Rectifier | No |
| Control / Protection | Oscillator, driver, current limiting, low standby current |
| Package / Case | 8-SOIC / SO-8 |
| Mounting Type | Surface Mount / SMD |
| Operating Temperature | -40°C to +85°C ambient reference range |
| Packaging | Tape and reel / cut tape options |
| Product Status | Active |
