AZ1117CH-ADJTRG1 – Diodes Incorporated Adjustable Positive LDO Linear Regulator
AZ1117CH-ADJTRG1 is a Diodes Incorporated adjustable low-dropout linear regulator designed for local voltage regulation, post-regulation and simple point-of-load power rails in electronic systems. With an adjustable positive output, 1.25V reference, 800mA output current rating, SOT-223 package, 70dB typical PSRR and built-in protection features, it is suitable for add-on cards, consumer electronics, embedded control boards, communication modules, USB-related circuits and general low-voltage power regulation designs.
Engineering note: Confirm input voltage, output voltage divider, dropout margin, load current, thermal pad copper area, output capacitor ESR, power dissipation and the latest Diodes Incorporated datasheet before production approval.
Component Overview
AZ1117CH-ADJTRG1 belongs to the Diodes Incorporated AZ1117C family of low-dropout three-terminal linear regulators. The adjustable version allows the output voltage to be set with two external resistors, making it useful for designs that need a flexible regulated rail rather than a fixed 1.2V, 1.5V, 1.8V, 2.5V, 3.3V or 5.0V output.
Circuit Function & Design Role
Provides a stable adjustable output voltage from a higher input rail with low design complexity.
Can clean up or fine-adjust a rail after a switching converter where lower ripple is needed.
Supports local supply rails for microcontrollers, logic circuits, interface ICs and small analog sections.
Includes current-limit and thermal shutdown features to improve robustness under overload conditions.
Key Electrical & Package Information
| Manufacturer | Diodes Incorporated |
|---|---|
| Part Number | AZ1117CH-ADJTRG1 |
| Series | AZ1117C / AZ1117CH Series |
| Device Type | Low-dropout linear voltage regulator |
| Regulator Polarity | Positive |
| Output Type | Adjustable |
| Reference Voltage | 1.25V |
| Output Current | 800mA distributor-listed value |
| Typical Current Limit | 1.35A reference value |
| Input Voltage Range | 3.2V to 15V distributor-listed value |
| Dropout Voltage | 1.2V typical reference value |
| Quiescent Current | 6mA maximum reference value |
| PSRR | 70dB typical reference value |
| Line Regulation | 0.001% reference value |
| Load Regulation | 0.4% reference value |
| Protection Features | Current limit, short-circuit current control, thermal shutdown |
| Package / Case | SOT-223-3 / SOT-223 |
| Mounting Type | Surface Mount / SMD |
| Operating Temperature | -20°C to +125°C |
| Packaging | Tape and reel / cut tape options |
| Factory Pack | 4,000 pcs |
Application Scenarios
Embedded Control Boards
Used to generate adjustable local rails for microcontrollers, sensors and support logic.
Consumer Electronics
Suitable for DVD players, audio products, add-on cards and general low-voltage subsystems.
Post-Regulator Rails
Applicable after a switching regulator where a cleaner adjustable linear rail is required.
General Power Management
Useful where a BOM requires an adjustable positive LDO regulator in SOT-223 package.
